规格 & 性能(Specifications & Performance) | |
载流量(Current-carrying) | 200A Max. |
额定电压（Operating voltage) | 1000V DC |
接线方式(Connection mode) | 六边压接（Six side pressure welding） |
适配线径(Fit for wire diameter) | 35 & 50m㎡ |
插针直径（DIM) | 8.0&10.0mm |
工作温度(Operating temperature) | -40~125℃ |
接触电阻(Contact resistance) | ≤0.3mΩ |
插拔寿命(Durability) | 500 mating cycles |
材质(Material) | 塑胶件：工程塑料(Plastic parts: Engineering plastics) |
插套：紫铜(Socket:Copper) | |
簧片：高性能铜合金(Spring:High performance copper alloy) | |
镀层(Plating) | 银(Silver) |
