产品详情
产品详情

规格 & 性能(Specifications & Performance)

载流量(Current-carrying)

80 ~ 200A Max.

额定电压(Operating voltage)

1000V DC

接线方式(Connection mode)

六边压接(Six side pressure welding)

适配线径(Fit for wire diameter)

16 ~ 50m㎡

插针直径(DIM)

6.0&8.0mm

工作温度(Operating temperature)

-40~125℃

接触电阻(Contact resistance)

≤0.3mΩ

插拔寿命(Durability)

500 mating cycles

材质(Material)

塑胶件:工程塑料(Plastic parts: Engineering plastics)

插套:紫铜(Socket:Copper)

簧片:高性能铜合金(Spring:High performance copper alloy)

镀层(Plating)

(Silver)
